4100S CapSense Pioneer Kit

The PSoC™ 4100S Max pioneer kit (CY8CKIT-041S-MAX) is a low-cost hardware platform that enables design and debug of the PSoC™ 4100S Max device.

Featuring the PSoC™ 4100S CapSense Pioneer Kit

The PSoC™ 4100S Max pioneer kit features the PSoC™ 4100S Max MCU (CY8C4149AZI-S598) with: 48-MHz Arm® Cortex®-M0+ core, 384KB of Flash, 32KB of SRAM, programmable analog blocks including a 12-bit SAR ADC, programmable digital blocks, cryptography accelerators, a CAN-FD interface, industry-leading capacitive-sensing with CAPSENSE™, and 84 GPIOs.

The PSoC™ 4100S Max pioneer kit (CY8CKIT-041S-MAX) is a low-cost hardware platform that enables design and debug of the PSoC™ 4100S Max device.

Featuring the PSoC™ 4100S Max MCU

The PSoC™ 4100S Max pioneer kit features the PSoC™ 4100S Max MCU (CY8C4149AZI-S598) with: 48-MHz Arm® Cortex®-M0+ core, 384KB of Flash, 32KB of SRAM, programmable analog blocks including a 12-bit SAR ADC, programmable digital blocks, cryptography accelerators, a CAN-FD interface, industry-leading capacitive-sensing with CAPSENSE™, and 84 GPIOs.

Introducing the 5th generation CAPSENSE™ based on Multi-Sense Convertor (MSC) technology, the PSoC™ 4100S Max pioneer kit comes with capacitive sensing interfaces including buttons, slider, touchpad and proximity sensor.

ModusToolbox software provides support for design and development of the PSoC™ 4100S Max pioneer kit. To download ModusToolbox software, please visit the ModusToolbox page. For code examples, please visit Infineon’s GitHub Repository.

Kit Contents:

• PSoC™ 4100S Max pioneer board
• Capacitive sensing expansion board
• USB Type-A to Micro-B cable
• Six jumper wires (five inches each)
• 40-pin FFC cable (2 inches)
• Quick start guide
